INA PHE35-XL

Specifications

Brand	INA
Item Number	PHE35-XL INA
Manufacturer Part Number	0008408230000
Also known as	PHE35
EAN	4012802788341
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	122
Width (B) MM	90
Inner (d) Inch	1.378
Outer (D) Inch	4.8031
Width (B) Inch	3.5433
Weight (kg)	1.32 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Length total (L) mm	122
Housing total width (M) mm	90
Width housing (A 2) mm	32
ECLASS number	23-05-16-03
ECLASS2 number	23-05-16-03
Medias description	Take-up housing units PHE, cast iron housing, radial insert ball bearing with eccentric locking collar, P seals

Suffix description

XL

X-Life
