INA PCJY35-XL-N

Specifications

Brand	INA
Item Number	PCJY35-XL-N INA
Manufacturer Part Number	0009512500000
Also known as	PCJY35-N
EAN	4012802823882
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	118
Width (B) MM	44,3
Inner (d) Inch	1.378
Outer (D) Inch	4.6457
Width (B) Inch	1.7441
Weight (kg)	1.3 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	118
Total height unit (U) mm	46,45
Radial Static Load Rating C0r (N)	15300
Radial Dynamic Load Rating Cr (N)	27500
Basic static load rating, radial (C 0r)	"15300.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units PCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, P seals

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
