INA PCJY20-XL-N

INA PCJY20-XL-N
INA PCJY20-XL-N rulman resim 1
INA PCJY20-XL-N rulman resim 2
INA PCJY20-XL-N rulman resim 3
Price: 22.55 $
Specifications
Brand INA
Item Number PCJY20-XL-N INA
Manufacturer Part Number 0009512770000
Also known as PCJY20-N
EAN 4012802823844
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 86
Width (B) MM 37,3
Inner (d) Inch 0.7874
Outer (D) Inch 3.3858
Width (B) Inch 1.4685
Weight (kg) 0.57 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 86
Total height unit (U) mm 37
Radial Static Load Rating C0r (N) 6600
Radial Dynamic Load Rating Cr (N) 13600
Basic static load rating, radial (C 0r) "6600.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units PCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, P seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
