INA PCJY15-XL
Price: 21.96 $
Specifications
| Brand | INA |
| Item Number | PCJY15-XL INA |
| Manufacturer Part Number | 0009504240000 |
| Also known as |
PCJY15 |
| EAN | 4012802824094 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 15 |
| Outer (D) MM | 76 |
| Width (B) MM | 32,9 |
| Inner (d) Inch | 0.5906 |
| Outer (D) Inch | 2.9921 |
| Width (B) Inch | 1.2953 |
| Weight (kg) | 0.43 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 76 |
| Total height unit (U) mm | 33 |
| Radial Static Load Rating C0r (N) | 4750 |
| Radial Dynamic Load Rating Cr (N) | 10100 |
| Basic static load rating, radial (C 0r) | "4750.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units PCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, P seals |
| XL | X-Life |
