INA PCJTY12-XL

Specifications

Brand	INA
Item Number	PCJTY12-XL INA
Manufacturer Part Number	0009492800000
Also known as	PCJTY12
EAN	4012802802160
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	98,5
Width (B) MM	32,9
Inner (d) Inch	0.4724
Outer (D) Inch	3.878
Width (B) Inch	1.2953
Weight (kg)	0.355 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	57
Height flange (H) mm	99
Total height unit (U) mm	33
Radial Static Load Rating C0r (N)	4750
Radial Dynamic Load Rating Cr (N)	10100
Basic static load rating, radial (C 0r)	"4750.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units PCJTY, two-bolt flanged housing units, cast iron, grub screws in inner ring, P seals

Suffix description

XL

X-Life
