INA PCJT35-XL-N-FA125
Price: 51.58 $
Specifications
| Brand | INA |
| Item Number | PCJT35-XL-N-FA125 INA |
| Manufacturer Part Number | 0096286570000 |
| Also known as |
PCJT35-N-FA125 |
| EAN | 4012802810066 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 35 |
| Outer (D) MM | 155 |
| Width (B) MM | 50,5 |
| Inner (d) Inch | 1.378 |
| Outer (D) Inch | 6.1024 |
| Width (B) Inch | 1.9882 |
| Weight (kg) | 1.13 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | With Corrotect® Coating |
| Flange width (L) mm | 92 |
| Height flange (H) mm | 155 |
| Total height unit (U) mm | 50,5 |
| Radial Static Load Rating C0r (N) | 15300 |
| Radial Dynamic Load Rating Cr (N) | 27500 |
| Basic static load rating, radial (C 0r) | "15300.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units PCJT..-FA125, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals, with anti-corrosion protection |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
| FA125 | With Corrotect® Coating, Protected Against Corrosion |
INA PCJT35-N-FA125
1.13 kg
35x155x50,5 mm
INA PCJT35N FA125
1.13 kg
35x155x50,5 mm
