INA PCJT30-XL-N

INA PCJT30-XL-N
INA PCJT30-XL-N rulman resim 1
INA PCJT30-XL-N rulman resim 2
INA PCJT30-XL-N rulman resim 3
INA PCJT30-XL-N rulman resim 4
Price: 35.70 $
Specifications
Brand INA
Item Number PCJT30-XL-N INA
Manufacturer Part Number 0096437290000
Also known as PCJT30-N
EAN 4012802837339
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 30
Outer (D) MM 141,5
Width (B) MM 46,7
Inner (d) Inch 1.1811
Outer (D) Inch 5.5709
Width (B) Inch 1.8386
Weight (kg) 0.95 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment
Data from Schaeffler (medias)
Flange width (L) mm 80
Height flange (H) mm 142
Total height unit (U) mm 46,8
Radial Static Load Rating C0r (N) 11300
Radial Dynamic Load Rating Cr (N) 20700
Basic static load rating, radial (C 0r) "11300.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units PCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
