INA PCJT25-XL-N-FA125

INA PCJT25-XL-N-FA125
INA PCJT25-XL-N-FA125 rulman resim 1
INA PCJT25-XL-N-FA125 rulman resim 2
INA PCJT25-XL-N-FA125 rulman resim 3
INA PCJT25-XL-N-FA125 rulman resim 4
INA PCJT25-XL-N-FA125 rulman resim 5
Price: 43.34 $
Specifications
Brand INA
Item Number PCJT25-XL-N-FA125 INA
Manufacturer Part Number 0096279950000
Also known as PCJT25-N-FA125
EAN 4012802810226
Category Housing and Bearing (assembly)
Weight and Dimensions
Inner (d) MM 25
Outer (D) MM 124
Width (B) MM 42,5
Inner (d) Inch 0.9843
Outer (D) Inch 4.8819
Width (B) Inch 1.6732
Weight (kg) 0.56 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment With Corrotect® Coating
Data from Schaeffler (medias)
Flange width (L) mm 70
Height flange (H) mm 124
Total height unit (U) mm 42,5
Radial Static Load Rating C0r (N) 7800
Radial Dynamic Load Rating Cr (N) 14900
Basic static load rating, radial (C 0r) "7800.0000"
ECLASS number 23-05-16-02
ECLASS2 number 23-05-16-02
Medias description Housing units PCJT..-FA125, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals, with anti-corrosion protection
Suffix description
XL X-Life
N Cast Iron Housing With Undercut Slot For End Caps
FA125 With Corrotect® Coating, Protected Against Corrosion
