INA PCJT25-TV-FA125-5

Specifications

Brand	INA
Item Number	PCJT25-TV-FA125.5 INA
Manufacturer Part Number	0573386200000
EAN	4012802831795
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	25
Outer (D) MM	130
Width (B) MM	40,5
Inner (d) Inch	0.9843
Outer (D) Inch	5.1181
Width (B) Inch	1.5945
Weight (kg)	0.33 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	With Corrotect® Coating

Data from Schaeffler (medias)

Flange width (L) mm	70
Height flange (H) mm	130
Total height unit (U) mm	40,5
Radial Static Load Rating C0r (N)	7800
Radial Dynamic Load Rating Cr (N)	14900
Basic static load rating, radial (C 0r)	"7100.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Flanged housing unit PCJT..-TV

Suffix description

TV	Plastic Housing
FA125,5	With Corrotect® Coating, Protected Against Corrosion
