INA PCJ30-XL-N
Price: 32.14 $
Specifications
| Brand | INA |
| Item Number | PCJ30-XL-N INA |
| Manufacturer Part Number | 0096409240000 |
| Also known as |
PCJ30-N |
| EAN | 4012802809442 |
| Category | Housing and Bearing (assembly) |
| Inner (d) MM | 30 |
| Outer (D) MM | 108 |
| Width (B) MM | 46,7 |
| Inner (d) Inch | 1.1811 |
| Outer (D) Inch | 4.252 |
| Width (B) Inch | 1.8386 |
| Weight (kg) | 1.095 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Flange width (L) mm | 108 |
| Total height unit (U) mm | 46,8 |
| Radial Static Load Rating C0r (N) | 11300 |
| Radial Dynamic Load Rating Cr (N) | 20700 |
| Basic static load rating, radial (C 0r) | "11300.0000" |
| ECLASS number | 23-05-16-02 |
| ECLASS2 number | 23-05-16-02 |
| Medias description | Housing units PCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, P seals |
| XL | X-Life |
| N | Cast Iron Housing With Undercut Slot For End Caps |
SKF FY30FM
1.095 kg
30x108x46,7 mm
RHP SF30EC
1.095 kg
30x108x46,7 mm
Asahi UDF206
1.095 kg
30x108x46,7 mm
HFB FY30FM
1.095 kg
30x108x46,7 mm
INA PCJ30-N
1.095 kg
30x108x46,7 mm
Fafnir PCF30
1.095 kg
30x108x46,7 mm
SNR ESFE206
1.095 kg
30x108x46,7 mm
Asahi UDF206A
1.095 kg
30x108x46,7 mm
FAG FG16206
1.095 kg
30x108x46,7 mm
FAG F16206
1.095 kg
30x108x46,7 mm
SKF FY30PF
1.095 kg
30x108x46,7 mm
SKF FY30LF
1.095 kg
30x108x46,7 mm
SKF FYK30FM
0.482 kg
30x108x46,7 mm
SKF FYK30FM/VL086
0.482 kg
30x108x46,7 mm
NTN AELF206
1.095 kg
30x108x46,7 mm
SNR SF30EC
1.095 kg
30x108x46,7 mm
NKE PCJ30-N
1.095 kg
30x108x46,7 mm
NTN AELF206D1
1.095 kg
30x108x46,7 mm
NTN M-AELF206D1
1.095 kg
30x108x46,7 mm
Nachi PCJ30
1.095 kg
30x108x46,7 mm
ZEN AELF206
1.095 kg
30x108x46,7 mm
Neutral UDF206
1.095 kg
30x108x46,7 mm
Neutral FY30FM
1.095 kg
30x108x46,7 mm
Neutral AELF206
1.095 kg
30x108x46,7 mm
Neutral AELF206-NEU
1.095 kg
30x108x46,7 mm
Neutral SF30EC
1.095 kg
30x108x46,7 mm
