INA PCFT20-XL

Specifications

Brand	INA
Item Number	PCFT20-XL INA
Manufacturer Part Number	0008314170000
Also known as	PCFT20
EAN	4012802791693
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	20
Outer (D) MM	112
Width (B) MM	34
Inner (d) Inch	0.7874
Outer (D) Inch	4.4094
Width (B) Inch	1.3386
Weight (kg)	0.4 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Flange width (L) mm	61
Height flange (H) mm	112
Total height unit (U) mm	34
Radial Static Load Rating C0r (N)	6600
Radial Dynamic Load Rating Cr (N)	13600
Basic static load rating, radial (C 0r)	"6600.0000"
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units PCFT, two-bolt flanged housing units, cast iron, eccentric locking collar, P seals

Suffix description

XL

X-Life
