INA NX15-Z-XL

Specifications

Brand	INA
Item Number	NX15-Z-XL INA
Manufacturer Part Number	0507791760000
Also known as	NX15-Z
EAN	4012802735789
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	15
Outer (D) MM	24
Width (B) MM	28
Inner (d) Inch	0.5906
Outer (D) Inch	0.9449
Width (B) Inch	1.1024
Weight (kg)	0.048 kg

Product Properties

Seal	Z - Steel Seal on One Side

Data from Schaeffler (medias)

Height (C) mm	28
Radial Static Load Rating C0r (N)	12700
Radial Dynamic Load Rating Cr (N)	12100
Axial Static Load Rating C0a (N)	10400
Axial Dynamic Load Rating Ca (N)	5600
Limiting speed (n G)	8000
ECLASS number	23-05-12-02
ECLASS2 number	23-05-12-02
Medias description	Needle roller/axial ball bearings NX..-Z, single direction axial component, for grease lubrication

Suffix description

Z	Shield Of Pressed Sheet Steel On One Side Of The Bearing
XL	X-Life
