INA NX12-Z-XL

Specifications

Brand	INA
Item Number	NX12-Z-XL INA
Manufacturer Part Number	0507791680000
Also known as	NX12-Z
EAN	4012802735772
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	21
Width (B) MM	18
Inner (d) Inch	0.4724
Outer (D) Inch	0.8268
Width (B) Inch	0.7087
Weight (kg)	0.0238 kg

Product Properties

Seal	Z - Steel Seal on One Side

Data from Schaeffler (medias)

Height (C) mm	18
Radial Static Load Rating C0r (N)	4300
Radial Dynamic Load Rating Cr (N)	5400
Axial Static Load Rating C0a (N)	8200
Axial Dynamic Load Rating Ca (N)	4850
Limiting speed (n G)	9500
ECLASS number	23-05-12-02
ECLASS2 number	23-05-12-02
Medias description	Needle roller/axial ball bearings NX..-Z, single direction axial component, for grease lubrication

Suffix description

Z	Shield Of Pressed Sheet Steel On One Side Of The Bearing
XL	X-Life
