INA NK40/20-TV-XL

INA NK40/20-TV-XL
INA NK40/20-TV-XL rulman resim 1
INA NK40/20-TV-XL rulman resim 2
INA NK40/20-TV-XL rulman resim 3
INA NK40/20-TV-XL rulman resim 4
Price: 18.78 $
Specifications
Brand INA
Item Number NK40/20-TV-XL INA
Manufacturer Part Number 0507542890000
Also known as NK40/20-TV
EAN 4012802733884
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 40
Outer (D) MM 50
Width (B) MM 20
Inner (d) Inch 1.5748
Outer (D) Inch 1.9685
Width (B) Inch 0.7874
Weight (kg) 0.083 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm 40
Radial Static Load Rating C0r (N) 56000
Radial Dynamic Load Rating Cr (N) 33500
Basic static load rating, radial (C 0r) "56000.0000"
Limiting speed (n G) 11400
Reference speed (n u03d1r) 6500
ECLASS number 23-05-09-07
ECLASS2 number 23-05-09-07
Medias description Needle roller bearings NK, light series
Suffix description
TV Polyamide Cage
XL X-Life
