INA NAO6X17X10-TV-IS1-XL

Specifications

Brand	INA
Item Number	NAO6X17X10-TV-IS1-XL INA
Manufacturer Part Number	0507777420000
Also known as	NAO6X17X10-TV-IS1
EAN	4047643330282
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	6
Outer (D) MM	17
Width (B) MM	10
Weight (kg)	0.014 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Width (b) mm	10
Radial Static Load Rating C0r (N)	5500
Radial Dynamic Load Rating Cr (N)	5300
Basic static load rating, radial (C 0r)	"5500.0000"
Limiting speed (n G)	29500
Reference speed (n u03d1r)	23800
ECLASS number	23-05-09-07
ECLASS2 number	23-05-09-07
Medias description	Needle roller bearings, without ribs, with inner ring, single row, with lubrication hole in the inner ring

Suffix description

TV	Polyamide Cage
IS1	One Lubrication Hole In The Inner Ring
XL	X-Life
