INA LR5006-2RS

Specifications

Brand	INA
Item Number	LR5006-2RS INA
Manufacturer Part Number	0008997470000
EAN	4012802807400
Category	Support Roller

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	62
Width (B) MM	19
Inner (d) Inch	1.1811
Outer (D) Inch	2.4409
Width (B) Inch	0.748
Weight (kg)	0.25 kg

Product Properties

Seal	2RS - Rubber Seal on Two Sides
Running Surface	Standard

Data from Schaeffler (medias)

Height (C) mm	19
Basic dynamic load rating, radial (C r w)	16100
Basic static load rating, radial (C 0r)	12200
Speed on permanent grease lubrication (n D G)	4000
ECLASS number	23-05-15-90
ECLASS2 number	23-05-15-90
Medias description	Track rollers LR50, double row, sealed on both sides

Suffix description

2RS	Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120u2103
