INA LCJT30-XL-N-SML

Specifications

Brand	INA
Item Number	LCJT30-XL-N-SML INA
Also known as	LCJT30-N-SML
Category	Housing and Bearing (assembly)

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	142
Width (B) MM	50,2
Inner (d) Inch	1.1811
Outer (D) Inch	5.5906
Width (B) Inch	1.9764
Weight (kg)	0.88 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Radial Static Load Rating C0r (N)	11300
Radial Dynamic Load Rating Cr (N)	20700
ECLASS number	23-05-16-02
ECLASS2 number	23-05-16-02
Medias description	Housing units LCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, L seals, for temperatures from -40°C to +180°C

Suffix description

XL	X-Life
N	Cast Iron Housing With Undercut Slot For End Caps
SML	More Clearance Between Bearings And Housing, This Has No Influence On The Item Without The Suffix SML
