INA KWVE55-B-S-V2-G3
Price: 364.85 $
Specifications
| Brand | INA |
| Item Number | KWVE55-B-S-V2-G3 INA |
| Manufacturer Part Number | 0202244350340 |
| Also known as |
KWVE55-B-S-G3-V2 |
| EAN | 4054366346599 |
| Category | Linear Plain Bearing Unit |
| Inner (d) MM | 53 |
| Outer (D) MM | 100 |
| Width (B) MM | 173,6 |
| Inner (d) Inch | 2.0866 |
| Outer (D) Inch | 3.937 |
| Width (B) Inch | 6.8346 |
| Weight (kg) | 4.35 kg |
| Seal | No Seal |
| Width carriage (B) mm | 100 |
| Overall length carriage (L) mm | 173,6 |
| Dynamic load rating (C) | 104000 |
| Static load rating (C 0) | 213000 |
| Static moment rating about X axis (M 0x) | 5600 |
| Static moment rating about Y axis (M 0y) | 2730 |
| Static moment rating about Z axis (M 0z) | 2730 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-S, narrow carriage, four-row |
| B | Version |
| S | Narrow Carriage |
| V2 | Preload Class 2 |
| G3 | Precision Class 3 |
