INA KWVE45-B-SN-V2-G3

INA KWVE45-B-SN-V2-G3
INA KWVE45-B-SN-V2-G3 rulman resim 1
INA KWVE45-B-SN-V2-G3 rulman resim 2
INA KWVE45-B-SN-V2-G3 rulman resim 3
INA KWVE45-B-SN-V2-G3 rulman resim 4
Price: 169.22 $
Specifications
Brand INA
Item Number KWVE45-B-SN-V2-G3 INA
Manufacturer Part Number 0200784390340
Also known as KWVE45-B-SN-G3-V2
EAN 4054366343727
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 86
Width (B) MM 140,6
Inner (d) Inch 1.7717
Outer (D) Inch 3.3858
Width (B) Inch 5.5354
Weight (kg) 2.12 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 86
Overall length carriage (L) mm 140,6
Dynamic load rating (C) 69000
Static load rating (C 0) 141000
Static moment rating about X axis (M 0x) 3610
Static moment rating about Y axis (M 0y) 2485
Static moment rating about Z axis (M 0z) 2485
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-SN, narrow, low carriage, four-row
Suffix description
B Version
SN Narrow, Low Carriage
V2 Preload Class 2
G3 Precision Class 3
