INA KWVE45-B-L-RROC-V1-G3

INA KWVE45-B-L-RROC-V1-G3
INA KWVE45-B-L-RROC-V1-G3 rulman resim 1
INA KWVE45-B-L-RROC-V1-G3 rulman resim 2
INA KWVE45-B-L-RROC-V1-G3 rulman resim 3
INA KWVE45-B-L-RROC-V1-G3 rulman resim 4
Price: 285.66 $
Specifications
Brand INA
Item Number KWVE45-B-L-RROC-V1-G3 INA
Manufacturer Part Number 0782206100240
Also known as KWVE45-B-L-RROC-G3-V1
EAN 4054364011383
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 45
Outer (D) MM 120
Width (B) MM 172,7
Inner (d) Inch 1.7717
Outer (D) Inch 4.7244
Width (B) Inch 6.7992
Weight (kg) 4.3 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 120
Overall length carriage (L) mm 172,7
Dynamic load rating (C) 82000
Static load rating (C 0) 181000
Static moment rating about X axis (M 0x) 4635
Static moment rating about Y axis (M 0y) 4000
Static moment rating about Z axis (M 0z) 4000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-L, long carriage, four-row, full complement ball set
Suffix description
B Version
L Long Carriage
RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V1 Slight Preload
G3 Precision Class 3
