INA KWVE35-B-NL-V1-G1

INA KWVE35-B-NL-V1-G1
INA KWVE35-B-NL-V1-G1 rulman resim 1
INA KWVE35-B-NL-V1-G1 rulman resim 2
INA KWVE35-B-NL-V1-G1 rulman resim 3
INA KWVE35-B-NL-V1-G1 rulman resim 4
INA KWVE35-B-NL-V1-G1 rulman resim 5
Price: 195.15 $
Specifications
Brand INA
Item Number KWVE35-B-NL-V1-G1 INA
Manufacturer Part Number 0200410120220
Also known as KWVE35-B-NL-G1-V1
EAN 4054366339591
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 100
Width (B) MM 145
Inner (d) Inch 1.3386
Outer (D) Inch 3.937
Width (B) Inch 5.7087
Weight (kg) 2.23 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 145
Dynamic load rating (C) 47500
Static load rating (C 0) 100000
Static moment rating about X axis (M 0x) 2625
Static moment rating about Y axis (M 0y) 1890
Static moment rating about Z axis (M 0z) 1890
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-NL, low, long carriage, four-row
Suffix description
B Version
NL Low, Long Carriage
V1 Slight Preload
G1 Precision Class 1
