INA KWVE35-B-EC-RROC-V1-G3

INA KWVE35-B-EC-RROC-V1-G3
INA KWVE35-B-EC-RROC-V1-G3 rulman resim 1
INA KWVE35-B-EC-RROC-V1-G3 rulman resim 2
INA KWVE35-B-EC-RROC-V1-G3 rulman resim 3
INA KWVE35-B-EC-RROC-V1-G3 rulman resim 4
INA KWVE35-B-EC-RROC-V1-G3 rulman resim 5
Price: 156.30 $
Specifications
Brand INA
Item Number KWVE35-B-EC-RROC-V1-G3 INA
Manufacturer Part Number 0782453620240
EAN 4054364011611
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 100
Width (B) MM 76,2
Inner (d) Inch 1.3386
Outer (D) Inch 3.937
Width (B) Inch 3
Weight (kg) 1.04 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 76,2
Dynamic load rating (C) 24600
Static load rating (C 0) 39000
Static moment rating about X axis (M 0x) 790
Static moment rating about Y axis (M 0y) 330
Static moment rating about Z axis (M 0z) 330
Suffix description
B Version
EC Expanded Design, Short Carriage (Carriage Without Screw Threads)
RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V1 Slight Preload
G3 Precision Class 3
