INA KWVE30-B-ESC-V0-G1
Price: 119.25 $
Specifications
| Brand | INA |
| Item Number | KWVE30-B-ESC-V0-G1 INA |
| Manufacturer Part Number | 0171884660120 |
| Also known as |
KWVE30-B-ESC-G1-V0 |
| EAN | 4054362994275 |
| Category | Linear Plain Bearing Unit |
| Inner (d) MM | 28 |
| Outer (D) MM | 60 |
| Width (B) MM | 69 |
| Inner (d) Inch | 1.1024 |
| Outer (D) Inch | 2.3622 |
| Width (B) Inch | 2.7165 |
| Weight (kg) | 0.57 kg |
| Seal | No Seal |
| Width carriage (B) mm | 60 |
| Overall length carriage (L) mm | 69 |
| Dynamic load rating (C) | 18700 |
| Static load rating (C 0) | 31500 |
| Static moment rating about X axis (M 0x) | 554 |
| Static moment rating about Y axis (M 0y) | 248 |
| Static moment rating about Z axis (M 0z) | 248 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set |
| B | Version |
| ESC | Expanded Design, Short, Narrow Carriage |
| V0 | Little To No Preload |
| G1 | Precision Class 1 |
