INA KWVE30-B-EC-V1-G1

INA KWVE30-B-EC-V1-G1
INA KWVE30-B-EC-V1-G1 rulman resim 1
INA KWVE30-B-EC-V1-G1 rulman resim 2
INA KWVE30-B-EC-V1-G1 rulman resim 3
INA KWVE30-B-EC-V1-G1 rulman resim 4
INA KWVE30-B-EC-V1-G1 rulman resim 5
Price: 119.25 $
Specifications
Brand INA
Item Number KWVE30-B-EC-V1-G1 INA
Manufacturer Part Number 0200283500220
Also known as KWVE30-B-EC-G1-V1
EAN 4054362993711
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 28
Outer (D) MM 90
Width (B) MM 69
Inner (d) Inch 1.1024
Outer (D) Inch 3.5433
Width (B) Inch 2.7165
Weight (kg) 0.75 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 90
Overall length carriage (L) mm 69
Dynamic load rating (C) 18700
Static load rating (C 0) 31500
Static moment rating about X axis (M 0x) 554
Static moment rating about Y axis (M 0y) 248
Static moment rating about Z axis (M 0z) 248
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row
Suffix description
B Version
EC Expanded Design, Short Carriage (Carriage Without Screw Threads)
V1 Slight Preload
G1 Precision Class 1
