INA KWVE25-WL-RROC-V1-G3

INA KWVE25-WL-RROC-V1-G3
INA KWVE25-WL-RROC-V1-G3 rulman resim 1
INA KWVE25-WL-RROC-V1-G3 rulman resim 2
INA KWVE25-WL-RROC-V1-G3 rulman resim 3
INA KWVE25-WL-RROC-V1-G3 rulman resim 4
INA KWVE25-WL-RROC-V1-G3 rulman resim 5
Price: 218.77 $
Specifications
Brand INA
Item Number KWVE25-WL-RROC-V1-G3 INA
Manufacturer Part Number 0773375900240
Also known as KWVE25-WL-RROC-G3-V1
EAN 4054369461138
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 69
Outer (D) MM 120
Width (B) MM 107,5
Inner (d) Inch 2.7165
Outer (D) Inch 4.7244
Width (B) Inch 4.2323
Weight (kg) 1.46 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 120
Overall length carriage (L) mm 107,5
Dynamic load rating (C) 23400
Static load rating (C 0) 54000
Static moment rating about X axis (M 0x) 2225
Static moment rating about Y axis (M 0y) 825
Static moment rating about Z axis (M 0z) 825
Suffix description
WL Wide, Long Carriage
RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V1 Slight Preload
G3 Precision Class 3
