INA KWVE25-B-SN-V1-G4

INA KWVE25-B-SN-V1-G4
INA KWVE25-B-SN-V1-G4 rulman resim 1
INA KWVE25-B-SN-V1-G4 rulman resim 2
INA KWVE25-B-SN-V1-G4 rulman resim 3
INA KWVE25-B-SN-V1-G4 rulman resim 4
INA KWVE25-B-SN-V1-G4 rulman resim 5
Price: 99.92 $
Specifications
Brand INA
Item Number KWVE25-B-SN-V1-G4 INA
Manufacturer Part Number 0114020320250
Also known as KWVE25-B-SN-G4-V1
EAN 4054362990482
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 23
Outer (D) MM 48
Width (B) MM 83,3
Inner (d) Inch 0.9055
Outer (D) Inch 1.8898
Width (B) Inch 3.2795
Weight (kg) 0.45 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 48
Overall length carriage (L) mm 83,3
Dynamic load rating (C) 17900
Static load rating (C 0) 37000
Static moment rating about X axis (M 0x) 510
Static moment rating about Y axis (M 0y) 395
Static moment rating about Z axis (M 0z) 395
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-SN, narrow, low carriage, four-row
Suffix description
B Version
SN Narrow, Low Carriage
V1 Slight Preload
G4 Precision Class 4
