INA KWVE25-B-L-RROC-V2-G3

INA KWVE25-B-L-RROC-V2-G3
INA KWVE25-B-L-RROC-V2-G3 rulman resim 1
INA KWVE25-B-L-RROC-V2-G3 rulman resim 2
INA KWVE25-B-L-RROC-V2-G3 rulman resim 3
INA KWVE25-B-L-RROC-V2-G3 rulman resim 4
INA KWVE25-B-L-RROC-V2-G3 rulman resim 5
Price: 177.23 $
Specifications
Brand INA
Item Number KWVE25-B-L-RROC-V2-G3 INA
Manufacturer Part Number 0706812870340
Also known as KWVE25-B-L-RROC-G3-V2
EAN 4054362984801
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 23
Outer (D) MM 70
Width (B) MM 109,1
Inner (d) Inch 0.9055
Outer (D) Inch 2.7559
Width (B) Inch 4.2953
Weight (kg) 1 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 70
Overall length carriage (L) mm 109,1
Dynamic load rating (C) 23400
Static load rating (C 0) 54000
Static moment rating about X axis (M 0x) 745
Static moment rating about Y axis (M 0y) 825
Static moment rating about Z axis (M 0z) 825
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-L, long carriage, four-row, full complement ball set
Suffix description
B Version
L Long Carriage
RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
V2 Preload Class 2
G3 Precision Class 3
