INA KWVE25-B-ESC-V2-G1

INA KWVE25-B-ESC-V2-G1
INA KWVE25-B-ESC-V2-G1 rulman resim 1
INA KWVE25-B-ESC-V2-G1 rulman resim 2
INA KWVE25-B-ESC-V2-G1 rulman resim 3
INA KWVE25-B-ESC-V2-G1 rulman resim 4
INA KWVE25-B-ESC-V2-G1 rulman resim 5
Price: 98.05 $
Specifications
Brand INA
Item Number KWVE25-B-ESC-V2-G1 INA
Manufacturer Part Number 0116942110320
Also known as KWVE25-B-ESC-G1-V2
EAN 4054362979838
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 23
Outer (D) MM 48
Width (B) MM 58,2
Inner (d) Inch 0.9055
Outer (D) Inch 1.8898
Width (B) Inch 2.2913
Weight (kg) 0.3 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 48
Overall length carriage (L) mm 58,2
Dynamic load rating (C) 12500
Static load rating (C 0) 22200
Static moment rating about X axis (M 0x) 305
Static moment rating about Y axis (M 0y) 155
Static moment rating about Z axis (M 0z) 155
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-B-ESC, narrow, short carriage, four-row, full complement ball set
Suffix description
B Version
ESC Expanded Design, Short, Narrow Carriage
V2 Preload Class 2
G1 Precision Class 1
