INA KWVE20-W-V1-G3

INA KWVE20-W-V1-G3
INA KWVE20-W-V1-G3 rulman resim 1
INA KWVE20-W-V1-G3 rulman resim 2
INA KWVE20-W-V1-G3 rulman resim 3
INA KWVE20-W-V1-G3 rulman resim 4
INA KWVE20-W-V1-G3 rulman resim 5
Price: 134.34 $
Specifications
Brand INA
Item Number KWVE20-W-V1-G3 INA
Manufacturer Part Number 0149659500240
Also known as KWVE20-W-G3-V1
EAN 4054362977759
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 42
Outer (D) MM 80
Width (B) MM 69,8
Inner (d) Inch 1.6535
Outer (D) Inch 3.1496
Width (B) Inch 2.748
Weight (kg) 0.5 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 80
Overall length carriage (L) mm 69,8
Dynamic load rating (C) 13100
Static load rating (C 0) 27000
Static moment rating about X axis (M 0x) 687
Static moment rating about Y axis (M 0y) 240
Static moment rating about Z axis (M 0z) 240
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly
Suffix description
W Wide Carriage
V1 Slight Preload
G3 Precision Class 3
