INA KWVE20-B-E-V2-G4

Specifications

Brand	INA
Item Number	KWVE20-B-E-V2-G4 INA
Manufacturer Part Number	0658220990350
Also known as	KWVE20-B-E-G4-V2
EAN	4054362969525
Category	Linear Plain Bearing Unit

Weight and Dimensions

Inner (d) MM	23,5
Outer (D) MM	59
Width (B) MM	71,4
Inner (d) Inch	0.9252
Outer (D) Inch	2.3228
Width (B) Inch	2.811
Weight (kg)	0.39 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Width carriage (B) mm	59
Overall length carriage (L) mm	71,4
Dynamic load rating (C)	13100
Static load rating (C 0)	27000
Static moment rating about X axis (M 0x)	332
Static moment rating about Y axis (M 0y)	240
Static moment rating about Z axis (M 0z)	240
ECLASS number	23-30-04-90
ECLASS2 number	23-30-04-90
Medias description	Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type

Suffix description

B	Standard Carriage, Four-Row, Full Complement Ball Set
E	Expanded Design (Carriage Without Screw Threads)
V2	Preload Class 2
G4	Precision Class 4
