INA KWSE35-L-V1-G3

INA KWSE35-L-V1-G3
INA KWSE35-L-V1-G3 rulman resim 1
INA KWSE35-L-V1-G3 rulman resim 2
INA KWSE35-L-V1-G3 rulman resim 3
INA KWSE35-L-V1-G3 rulman resim 4
INA KWSE35-L-V1-G3 rulman resim 5
Price: 242.64 $
Specifications
Brand INA
Item Number KWSE35-L-V1-G3 INA
Manufacturer Part Number 0028659710240
Also known as KWSE35-L-G3-V1
EAN 4054362955924
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 34
Outer (D) MM 100
Width (B) MM 41,4
Inner (d) Inch 1.3386
Outer (D) Inch 3.937
Width (B) Inch 1.6299
Weight (kg) 2.1 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 100
Overall length carriage (L) mm 138,9
Dynamic load rating, load direction I: compressive load (I C) 70000
Static load rating, load direction I: compressive load (I C 0) 145000
Dynamic load rating, load direction II: tensile load (II C) 67500
Static load rating, load direction II: tensile load (II C 0) 119000
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 71000
Static load rating, Load direction III: lateral load (III C 0) 125000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description Long carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
L Long Carriage
V1 Slight Preload
G3 Precision Class 3
