INA KWSE20-V1-G3
Price: 130.45 $
Specifications
| Brand | INA |
| Item Number | KWSE20-V1-G3 INA |
| Manufacturer Part Number | 0007729250240 |
| Also known as |
KWSE20-G3-V1 |
| EAN | 4054362941521 |
| Category | Linear Plain Bearing Unit |
| Inner (d) MM | 20 |
| Outer (D) MM | 63 |
| Width (B) MM | 70,9 |
| Inner (d) Inch | 0.7874 |
| Outer (D) Inch | 2.4803 |
| Width (B) Inch | 2.7913 |
| Weight (kg) | 0.43 kg |
| Seal | No Seal |
| Width carriage (B) mm | 63 |
| Overall length carriage (L) mm | 71,4 |
| Dynamic load rating, load direction I: compressive load (I C) | 22000 |
| Static load rating, load direction I: compressive load (I C 0) | 52000 |
| Dynamic load rating, load direction II: tensile load (II C) | 21300 |
| Static load rating, load direction II: tensile load (II C 0) | 35300 |
| Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) | 21000 |
| Static load rating, Load direction III: lateral load (III C 0) | 35000 |
| ECLASS number | 23-30-04-90 |
| ECLASS2 number | 23-30-04-90 |
| Medias description | Standard carriage for six-row linear recirculating ball bearing and guideway assembly |
| V1 | Slight Preload |
| G3 | Precision Class 3 |
