INA KWSE20-H-V1-G2

INA KWSE20-H-V1-G2
INA KWSE20-H-V1-G2 rulman resim 1
INA KWSE20-H-V1-G2 rulman resim 2
INA KWSE20-H-V1-G2 rulman resim 3
INA KWSE20-H-V1-G2 rulman resim 4
INA KWSE20-H-V1-G2 rulman resim 5
Price: 143.64 $
Specifications
Brand INA
Item Number KWSE20-H-V1-G2 INA
Manufacturer Part Number 0007729330230
Also known as KWSE20-H-G2-V1
EAN 4054362939498
Category Linear Plain Bearing Unit
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 44
Width (B) MM 70,9
Inner (d) Inch 0.7874
Outer (D) Inch 1.7323
Width (B) Inch 2.7913
Weight (kg) 0.32 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Width carriage (B) mm 44
Overall length carriage (L) mm 71,4
Dynamic load rating, load direction I: compressive load (I C) 22000
Static load rating, load direction I: compressive load (I C 0) 52000
Dynamic load rating, load direction II: tensile load (II C) 21300
Static load rating, load direction II: tensile load (II C 0) 35300
Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 21000
Static load rating, Load direction III: lateral load (III C 0) 35000
ECLASS number 23-30-04-90
ECLASS2 number 23-30-04-90
Medias description High, narrow carriage for six-row linear recirculating ball bearing and guideway assembly
Suffix description
H High Carriage
V1 Slight Preload
G2 Precision Class 2
