INA KBK12X15X15-A(CS)/0-2

Price: 6.49 $

Specifications

Brand	INA
Item Number	KBK12X15X15-A(CS)/0-2 INA
Manufacturer Part Number	0007876470061
EAN	4012802723441
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	15
Width (B) MM	15
Inner (d) Inch	0.4724
Outer (D) Inch	0.5906
Width (B) Inch	0.5906
Weight (kg)	0.006 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	12
Outside diameter of needle roller complement (E w) mm	15
Width (B c) mm	15
Radial Static Load Rating C0r (N)	7900
Radial Dynamic Load Rating Cr (N)	6000
Basic static load rating, radial (C 0r)	"7900.0000"
Limiting speed (n G)	27000
ECLASS number	23-05-09-04
ECLASS2 number	23-05-09-04
Medias description	Needle roller cage assembly KBK, single row, similar KBK, piston pin bearing

Suffix description

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307). (CS)=Factory Location Code, No Additional Meaning. Can Be Used As Standard

/0-2

Micron - Needle Sort
