INA HK2520-AS1-B

Price: 5.05 $

Specifications

Brand	INA
Item Number	HK2520-AS1-B INA
Manufacturer Part Number	0067549450000
EAN	4012802430516
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	25
Outer (D) MM	32
Width (B) MM	20
Inner (d) Inch	0.9843
Outer (D) Inch	1.2598
Width (B) Inch	0.7874
Weight (kg)	0.033 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	25
Width (C) mm	20
Basic static load rating, radial (C 0r)	33000
Limiting speed (n G)	10200
Limiting speed for grease lubrication (n G Grease)	6100
Reference speed (n u03d1r)	7400
ECLASS number	23-05-09-05
ECLASS2 number	23-05-09-05

Suffix description

AS1

Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
