INA HK1816-AS1-B

Price: 4.22 $

Specifications

Brand	INA
Item Number	HK1816-AS1-B INA
Manufacturer Part Number	0000606310000
EAN	4012802444520
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	18
Outer (D) MM	24
Width (B) MM	16
Inner (d) Inch	0.7087
Outer (D) Inch	0.9449
Width (B) Inch	0.6299
Weight (kg)	0.017 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	18
Width (C) mm	16
Radial Static Load Rating C0r (N)	17300
Radial Dynamic Load Rating Cr (N)	11600
Basic static load rating, radial (C 0r)	"17300.0000"
Limiting speed (n G)	14000
Limiting speed for grease lubrication (n G Grease)	8400
Reference speed (n u03d1r)	10400
ECLASS number	23-05-09-05
ECLASS2 number	23-05-09-05
Medias description	Drawn cup needle roller bearing open end HK..-AS1-B, single row, with cage

Suffix description

AS1

Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
