INA HK1210-AS1-B

Price: 4.22 $

Specifications

Brand	INA
Item Number	HK1210-AS1-B INA
Manufacturer Part Number	0011977200000
EAN	4012802419863
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	12
Outer (D) MM	16
Width (B) MM	10
Inner (d) Inch	0.4724
Outer (D) Inch	0.6299
Width (B) Inch	0.3937
Weight (kg)	0.0044 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	12
Width (C) mm	10
Radial Static Load Rating C0r (N)	6200
Radial Dynamic Load Rating Cr (N)	4950
Basic static load rating, radial (C 0r)	"6200.0000"
Limiting speed (n G)	20700
Limiting speed for grease lubrication (n G Grease)	12400
Reference speed (n u03d1r)	15700
ECLASS number	23-05-09-05
ECLASS2 number	23-05-09-05
Medias description	Drawn cup needle roller bearing open end HK..-AS1-B, single row, with cage

Suffix description

AS1

Needle Roller Bearing With Lubrication Hole(s) In The Outer Ring. A Figure Following The As Indicates The Number Of Holes

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
