INA HFLZ101416-L564

Specifications

Brand	INA
Item Number	HFLZ101416-L564 INA
Manufacturer Part Number	0016002650962
Also known as	HFLZ101416
EAN	4047643183147
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	15,875
Outer (D) MM	22,225
Width (B) MM	25,4
Inner (d) Inch	0.625
Outer (D) Inch	0.875
Width (B) Inch	1
Weight (kg)	0.023 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	15,875
Radial Static Load Rating C0r (N)	8500
Radial Dynamic Load Rating Cr (N)	7400
Basic static load rating, radial (C 0r)	"8500.0000"
Limiting speed for rotating shaft (n GW)	8500
Limiting speed for rotating outer ring (n GA)	5000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFLZ, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
