INA HFL3530-L564

INA HFL3530-L564
INA HFL3530-L564 rulman resim 1
INA HFL3530-L564 rulman resim 2
INA HFL3530-L564 rulman resim 3
INA HFL3530-L564 rulman resim 4
Price: 41.08 $
Specifications
Brand INA
Item Number HFL3530-L564 INA
Manufacturer Part Number 0016002570962
Also known as HFL3530
EAN 4012802042702
Category Needle Roller and Cage Assembly
Weight and Dimensions
Inner (d) MM 35
Outer (D) MM 42
Width (B) MM 30
Inner (d) Inch 1.378
Outer (D) Inch 1.6535
Width (B) Inch 1.1811
Weight (kg) 0.058 kg
Product Properties
Seal No Seal
Data from Schaeffler (medias)
Under roller diameter (F w) mm 35
Radial Static Load Rating C0r (N) 18800
Radial Dynamic Load Rating Cr (N) 12200
Basic static load rating, radial (C 0r) "18800.0000"
Limiting speed for rotating shaft (n GW) 3900
Limiting speed for rotating outer ring (n GA) 3900
ECLASS number 23-05-21-90
ECLASS2 number 23-05-21-90
Medias description Drawn cup roller clutch HFL, with bearing
Suffix description
L564 Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
