INA HFL3030-L564

Specifications

Brand	INA
Item Number	HFL3030-L564 INA
Manufacturer Part Number	0016002490962
Also known as	HFL3030
EAN	4012802106732
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	30
Outer (D) MM	37
Width (B) MM	30
Inner (d) Inch	1.1811
Outer (D) Inch	1.4567
Width (B) Inch	1.1811
Weight (kg)	0.055 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	30
Radial Static Load Rating C0r (N)	16900
Radial Dynamic Load Rating Cr (N)	11600
Basic static load rating, radial (C 0r)	"16900.0000"
Limiting speed for rotating shaft (n GW)	4500
Limiting speed for rotating outer ring (n GA)	4500
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
