INA HFL1022-L564

Specifications

Brand	INA
Item Number	HFL1022-L564 INA
Manufacturer Part Number	0016001680962
Also known as	HFL1022
EAN	4012802369588
Category	Needle Roller and Cage Assembly

Weight and Dimensions

Inner (d) MM	10
Outer (D) MM	14
Width (B) MM	22
Inner (d) Inch	0.3937
Outer (D) Inch	0.5512
Width (B) Inch	0.8661
Weight (kg)	0.008 kg

Product Properties

Seal

No Seal

Data from Schaeffler (medias)

Under roller diameter (F w) mm	10
Radial Static Load Rating C0r (N)	4500
Radial Dynamic Load Rating Cr (N)	3950
Basic static load rating, radial (C 0r)	"4500.0000"
Limiting speed for rotating shaft (n GW)	14000
Limiting speed for rotating outer ring (n GA)	11000
ECLASS number	23-05-21-90
ECLASS2 number	23-05-21-90
Medias description	Drawn cup roller clutch HFL, with bearing

Suffix description

L564	Centoplex 1 Dl/2 Dl Are Low-Temperature Greases Based On An Oxidation-Resistant Mineral Oil And A Lithium-Calcium Soap. Due To The Good Resistance To Working Under Normal Temperatures And Loads These Greases Can Be Used For Long-Term Lubrication
