INA GYE12-KRR-B-VA-HLA
Price: 61.88 $
Specifications
| Brand | INA |
| Item Number | GYE12-KRR-B-VA-HLA INA |
| Manufacturer Part Number | 0530917440000 |
| Also known as |
GYE12-KRR-B-VA |
| EAN | 4054362377641 |
| Category | Bearings for Housings |
| Inner (d) MM | 12 |
| Outer (D) MM | 40 |
| Width (B) MM | 25 |
| Inner (d) Inch | 0.4724 |
| Outer (D) Inch | 1.5748 |
| Width (B) Inch | 0.9843 |
| Weight (kg) | 0.119 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | Stainless Steel Bearing |
| Outside diameter (D SP) mm | 40 |
| Width (b) mm | 25 |
| Radial Static Load Rating C0r (N) | 4550 |
| Radial Dynamic Load Rating Cr (N) | 9200 |
| Basic static load rating, radial (C 0r) | "4550.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearing GYE..-KRR-B-VA |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
| VA | Corrosion-Resistant Design Made From High Alloy Rolling Bearing Steel |
| HLA | Factory Location Code, No Additional Meaning. Can Be Used As Standard |
INA GYE12-KRR-B-VA-HLC
0.119 kg
12x40x25 mm
INA GYE12KRRBVA
0.119 kg
12x40x25 mm
INA GYE12-KRR-B-VA
0.119 kg
12x40x25 mm
