INA GRAE20-NPP-B-FA106

INA GRAE20-NPP-B-FA106
INA GRAE20-NPP-B-FA106 rulman resim 1
INA GRAE20-NPP-B-FA106 rulman resim 2
INA GRAE20-NPP-B-FA106 rulman resim 3
INA GRAE20-NPP-B-FA106 rulman resim 4
INA GRAE20-NPP-B-FA106 rulman resim 5
Price: 18.21 $
Specifications
Brand INA
Item Number GRAE20-NPP-B-FA106 INA
Manufacturer Part Number 0008404240000
Also known as YET204
EAN 4012802788686
Category Bearings for Housings
Weight and Dimensions
Inner (d) MM 20
Outer (D) MM 47
Width (B) MM 31
Inner (d) Inch 0.7874
Outer (D) Inch 1.8504
Width (B) Inch 1.2205
Weight (kg) 0.18 kg
Product Properties
Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment FA106
Data from Schaeffler (medias)
Outside diameter (D SP) mm 47
Width (b) mm 21,4
Locking collar total width (B 1) mm 31
Radial Static Load Rating C0r (N) 6600
Radial Dynamic Load Rating Cr (N) 13600
Basic static load rating, radial (C 0r) "6600.0000"
ECLASS number 23-05-08-02
ECLASS2 number 23-05-08-02
Medias description Radial insert ball bearing GRAE..-NPP-B
Suffix description
NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
B Bearing With Spherical Outer Ring
FA106 Bearing Subjected To Special Noise Testing
