INA GNE80-XL-KRR-B
Price: 298.00 $
Specifications
| Brand | INA |
| Item Number | GNE80-XL-KRR-B INA |
| Manufacturer Part Number | 0008838910000 |
| Also known as |
GNE80-KRR-B |
| EAN | 4012802809107 |
| Category | Bearings for Housings |
| Inner (d) MM | 80 |
| Outer (D) MM | 170 |
| Width (B) MM | 93,6 |
| Inner (d) Inch | 3.1496 |
| Outer (D) Inch | 6.6929 |
| Width (B) Inch | 3.685 |
| Weight (kg) | 7.1 kg |
| Seal | 2F - Standard Seal for Y-bearings |
| Lubrication | Standard Lubrication |
| Special Treatment | No Special Treatment |
| Outside diameter (D SP) mm | 170 |
| Width (b) mm | 73 |
| Locking collar total width (B 1) mm | 93,6 |
| Radial Static Load Rating C0r (N) | 87000 |
| Radial Dynamic Load Rating Cr (N) | 131000 |
| Basic static load rating, radial (C 0r) | "87000.0000" |
| ECLASS number | 23-05-08-02 |
| ECLASS2 number | 23-05-08-02 |
| Medias description | Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides |
| XL | X-Life |
| KRR | Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder) |
| B | Bearing With Spherical Outer Ring |
