INA GNE60-XL-KRR-B

Specifications

Brand	INA
Item Number	GNE60-XL-KRR-B INA
Manufacturer Part Number	0009445210000
Also known as	GNE60-KRR-B
EAN	4012802803600
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	60
Outer (D) MM	130
Width (B) MM	68
Inner (d) Inch	2.3622
Outer (D) Inch	5.1181
Width (B) Inch	2.6772
Weight (kg)	2.97 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	130
Width (b) mm	52
Locking collar total width (B 1) mm	68
Radial Static Load Rating C0r (N)	52000
Radial Dynamic Load Rating Cr (N)	87000
Basic static load rating, radial (C 0r)	"52000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
