INA GNE35-XL-KRR-B

Specifications

Brand	INA
Item Number	GNE35-XL-KRR-B INA
Manufacturer Part Number	0009918210000
Also known as	GNE35-KRR-B
EAN	4012802816402
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	35
Outer (D) MM	80
Width (B) MM	51,6
Inner (d) Inch	1.378
Outer (D) Inch	3.1496
Width (B) Inch	2.0315
Weight (kg)	0.73 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	80
Width (b) mm	38,1
Locking collar total width (B 1) mm	51,6
Radial Static Load Rating C0r (N)	20900
Radial Dynamic Load Rating Cr (N)	39000
Basic static load rating, radial (C 0r)	"20900.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GNE..-KRR-B, spherical outer ring, location by eccentric locking collar, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
