INA GLE70-XL-KRR-B

Specifications

Brand	INA
Item Number	GLE70-XL-KRR-B INA
Manufacturer Part Number	0008389180000
Also known as	GLE70-KRR-B
EAN	4012802788938
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	70
Outer (D) MM	125
Width (B) MM	68,2
Inner (d) Inch	2.7559
Outer (D) Inch	4.9213
Width (B) Inch	2.685
Weight (kg)	1.9 kg

Product Properties

Seal	2RS - Rubber Seal on Two Sides
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	125
Width (b) mm	68,2
Radial Static Load Rating C0r (N)	44000
Radial Dynamic Load Rating Cr (N)	66000
Basic static load rating, radial (C 0r)	"44000.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GLE..-KRR-B, spherical outer ring, non-locating bearing, drive slot in inner ring, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
