INA GLE50-XL-KRR-B

Specifications

Brand	INA
Item Number	GLE50-XL-KRR-B INA
Manufacturer Part Number	0008530700000
Also known as	GLE50-KRR-B
EAN	4012802799538
Category	Bearings for Housings

Weight and Dimensions

Inner (d) MM	50
Outer (D) MM	90
Width (B) MM	49,2
Inner (d) Inch	1.9685
Outer (D) Inch	3.5433
Width (B) Inch	1.937
Weight (kg)	0.76 kg

Product Properties

Seal	2F - Standard Seal for Y-bearings
Lubrication	Standard Lubrication
Special Treatment	No Special Treatment

Data from Schaeffler (medias)

Outside diameter (D SP) mm	90
Width (b) mm	49,2
Radial Static Load Rating C0r (N)	23200
Radial Dynamic Load Rating Cr (N)	37500
Basic static load rating, radial (C 0r)	"23200.0000"
ECLASS number	23-05-08-02
ECLASS2 number	23-05-08-02
Medias description	Radial insert ball bearings GLE..-KRR-B, spherical outer ring, non-locating bearing, drive slot in inner ring, R seals on both sides

Suffix description

XL	X-Life
KRR	Lip Seals On Both Sides (R Type Seal - Has A Zinc Plated Inner And Outer Cover. Between The Covers There Is An NBR Seal Lip Running On A Ground Shoulder)
B	Bearing With Spherical Outer Ring
