INA GIKR5-PW-A

Price: 35.17 $

Specifications

Brand	INA
Item Number	GIKR5-PW-A INA
Manufacturer Part Number	0066350830000
Also known as	SIKB5F
EAN	4012802526240
Category	Rod End

Weight and Dimensions

Inner (d) MM	5
Outer (D) MM	18
Width (B) MM	8
Inner (d) Inch	0.1969
Outer (D) Inch	0.7087
Width (B) Inch	0.315
Weight (kg)	0.0184 kg

Product Properties

Seal	No Seal
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	13
Radial Static Load Rating C0r (N)	9180
Width inner ring (B) mm	8
Radial Dynamic Load Rating Cr (N)	6000
Basic static load rating, radial (C 0r)	"9180.0000"
ECLASS number	23-05-01-05
ECLASS2 number	23-05-01-05
Medias description	Rod end with internal thread, right hand thread, maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design

Suffix description

Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
