INA GE50-AW-A

Price: 346.88 $

Specifications

Brand	INA
Item Number	GE50-AW-A INA
Manufacturer Part Number	0066517550000
EAN	4012802532609
Category	Spherical Plain Bearing

Weight and Dimensions

Inner (d) MM	50
Outer (D) MM	130
Width (B) MM	42,5
Inner (d) Inch	1.9685
Outer (D) Inch	5.1181
Width (B) Inch	1.6732
Weight (kg)	3.2 kg

Product Properties

Seal	No Seal
Contact Material	Steel on PTFE

Data from Schaeffler (medias)

Outside diameter bearing (D) mm	130
Height (T) mm	42,5
Width inner ring (B) mm	33,5
Axial Static Load Rating C0a (N)	3250000
Axial Dynamic Load Rating Ca (N)	1950000
ECLASS number	23-05-01-06
ECLASS2 number	23-05-01-06
Medias description	Axial spherical plain bearing, maintenance-free, DIN ISO 12240-3, shaft location washer curved surface with hard chromium coating, open design

Suffix description

Sliding Contact Surface Hard Chromium/Elgoglide® (Elgoglide®=PTFE (Polyetrafluoroethylene))

The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)
